Acorn BBC - Model B+ Service Manual
SECTION 2 BBC Microcomputer Model B+
BBC Microcomputer Model B+ Service Manual
Contents
1 – Introduction 1
2 – Packaging and installation 2
3 – Specification 3
3.1 The microcomputer 3
3.2 Power supply 5
3.3 Video outputs 5
3.4 RS423 5
3.5 Cassette interface 6
3.6 Analogue to digital convertor 6
3.7 ECONET 6
3.8
Centronics compatible printer interface 6
3.9 Audio output 6
3.10 Environnent 7
3.11 Dimensions 7
4 – Disassembly and assembly 8
5 – Circuit description 10
5.1 General 10
5.2 CPU timing 11
5.3 Reset circuitry 13
5.4 Address decoding and memory 13
5.4.1 ROM operation 15
5.4.2 Paged RAM operation 16
5.4.3 RAM. access 16
5.4.4 RAM circuitry 18
5.5 Disc interface 19
5.5.1 8271 FDC 19
5.5.2 1770 FDC 21
5.6 Video circuitry 21
5.6.1
RGB 21
5.6.2 Composite video 21
5.6.3 UHF 22
5.7
Centronics compatible printer interface 23
5.8 User port 23
5.9 1MHz extension bus 23
5.10 TUBE interface 23
5.11 ECONET 24
5.12 Cassette and RS423 ports 24
5.13 Analogue to digital convertor 25
5.14 Audio circuitry 25
5.15 Keyboard 26
6 – Upgrading the
PCB 27
6.1 1770 disc option 27
6.2 8271 disc option 28
6.3 ECONET 30
6.4 Speech 31
7 - Selection links 33
8 – Test equipment 35
9 – Fault finding 36
9.1 Switch on 36
9.2 Power supply 39
9.3 Oscillator and divider circuitry 40
9.4 CPU 40
9.5 ROM 41
9.6
DRAMs 42
9.7 Video 42
9.8 Cassette interface and RS423 45
9.9 Keyboard 47
9.10 Disc interface 48
9.11 Printer port 51
9.12 User port 52
9.13 1MHz extension bus 53
9.14 TUBE interface 54
9.15 Analogue to digital conversion 55
9.16 ECONET 56
Appendix 57
Connector pinouts 58
Parts list 63
Glossary 69
IC description 71
Final assembly 89
Circuit block diagram 91
PCB circuit diagram 93
PCB layout 95
Keyboard circuit diagram 97
Power supply circuit diagram 99
WARNING: THE COMPUTER MUST BE EARTHED
IMPORTANT: The wires in the mains lead for the apparatus are coloured in accordance with the following code:
Green & Yellow Earth
Blue Neutral
Brown Live
The moulded plug must be used with the fuse and fuse carrier firmly in place. The fuse carrier is of the same basic colour (though not necessarily the same shade of that colour) as the coloured insert in the base of the plug. Different manufacturers' plugs and fuse carriers are not interchangeable. In the event of loss of the fuse carrier, the moulded plug MUST NOT be used. Either replace the moulded plug with another conventional plug wired as detailed below, or obtain a replacement fuse carrier from an authorised ACORN dealer. In the event of the fuse blowing it should be replaced, after clearing any faults, with a 3 amp fuse that is ASTA approved to BS1362.
If the socket outlet available is not suitable for the plug supplied, the plug should be cut off and the appropriate plug fitted and wired as previously noted. The moulded plug which was cut off must be disposed of as it would be a potential shock hazard if it were to be plugged in with the cut off end of the mains cord exposed.
As the colours of the wires may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured green and yellow must be connected to the terminal in the plug which is marked by the letter E, or by the safety earth symbol ^ , or coloured either green or green and yellow.
The wire which is coloured blue must be connected to the terminal which is marked with the letter N, or coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the letter L, or coloured red.
1 Introduction
This manual is intended to provide the information required to diagnose and repair faults on the BBC Microcomputer Model B+ which was designed by ACORN Computers Ltd of Cambridge, England.
The information contained in this manual is aimed at service engineers and ACORN dealers who will be servicing the BBC Microcomputer on behalf of ACORN Computers Ltd.
2 Packaging and installation
The microcomputer is supplied in a two-part moulded polystyrene packing in a cardboard box. Supplied with the microcomputer is a User Guide, an introductory cassette package, a UHF TV lead, and a guarantee registration card. Disc and Econet versions also contain a Disc Filing System User Guide and an Econet User Guide respectively.
The mains supply for UK models is 240V AC 50Hz. The microcomputer is supplied with a moulded l3 amp square pin plug. If this plug is unsuitable then it must be cut off and thrown away. Instructions for fitting a replacement plug are given right at the front of this manual.
The microcomputer is turned on by a switch at the back of the microcomputer next to the mains lead.
Do not use the microcomputer in conditions of extreme heat, cold, humidity or dust or in places subject to vibration. Do not block ventilation under or behind the computer. Ensure that no foreign objects are inserted through any openings in the microcomputer.
3 Specification
3.1 The microcomputer
The microcomputer is contained in a rigid injection moulded thermoplastic case, and provides the following facilities.
73 key full travel QWERTY keyboard including 10 user-definable function keys. Keyboard has two key rollover and auto repeat.
Fully encased internal power supply manufactured to BS 4l5 Class 1.
Internal loudspeaker driven from a 4-channel sound synthesis circuit with ADSR envelope control.
A colour television signal, for connection to a normal domestic television aerial socket, is available through a phono connector. This signal is 625 line, 50Hz, interlaced, encoded PAL A and is modulated on UHF channel 36.
A BNC connector supplies a composite video output to drive a black and white or PAL colour monitor.
6-pin DIN connector provides separate
RGB and sync outputs at TTL levels.
RGB are all high true, and sync is link selectable as high or low true, pulse duration 4.0 microseconds.
A standard audio cassette recorder can be used to record computer programs and data at 300 or 1200 baud using the Computer Users' Tape Standard tones. The cassette recorder is under automatic motor control and is connected to the computer via a 7-pin DIN connector.
An interrupt driven elapsed time clock (user settable).
6512A processor running at 2MHz.
64K of read/write Random Access Memory (RAM), allowing a shadow screen mode, and 12K paged RAM in any mode.
32K Read Only Memory (ROM) integrated circuit containing the Machine Operating System and a fast BASIC interpreter. The interpreter includes a 6502/6512 assembler which enables BASIC statements to be freely mixed with 6502/6512 assembly language. Code generated using the BASIC assembler can be run on a machine with a 6512 microprocessor, or a machine with a 6502 microprocessor.
Up to five 32K sideways ROMs may be plugged into the machine at any time, having the effect of ten l6K ROM slots (eleven including BASIC). These ten 16K ROM slots are paged and may include Pascal, word processing, computer aided design software, disc and ECONET and WINCHESTER filing systems or TELETEXT acquisition software.
The full-colour Teletext display of 40 characters by 25 lines, known as mode 7 has character rounding, with double height, flashing, coloured background and text plus pixel graphics – all to the Teletext standard.
The non-Teletext display modes (modes 0 to 6) provide user-definable characters in addition to the standard upper and lower case alpha-numeric font. In these modes, graphics may be mixed freely with text.
The following screen modes are available:
Mode 0: 640 x 256 2-colour graphics and 80 x 32 text (20K)
Mode 1: 320 x 256 4-colour graphics and 40 x 32 text (20K)
Mode 2: 160 x 256 16-colour graphics and 20 x 32 text (20K)
Mode 3: 80 x 25 2-colour text only (16K)
Mode 4: 320 x 256 2-colour graphics and 40 x 32 text (10K)
Mode 5: 160 x 256 4-colour graphics and 20 x 32 text (10K)
Mode 6: 40 x 25 2-colour text only (8K)
Mode 7: 40 x 25 Teletext display (1K)
Mode 128: 640 x 256 2-colour graphics and 80 x 32 text (20K)
Mode 129: 320 x 256 4-colour graphics and 40 x 32 text (20K)
Mode 130: 160 x 256 16-colour graphics and 20 x 32 text (20K)
Mode 131: 80 x 25 2-colour text only (16K)
Mode 132: 320 x 256 2-colour graphics and 40 x 32 text (10K)
Mode 133: 160 x 256 4-colour graphics and 20 x 32 text (10K)
Mode 134: 40 x 25 2-colour text only (8K)
Mode 135: 40 x 25 Teletext display (1K)
All graphics access is transparent.
Shadow mode gives 32K BASIC program RAM (less workspace) to the user in any screen mode.
The shadow screen mode offers equivalent display sizes to the standard mode 0 to 7 screens, but using an auxiliary memory area, the "shadow" RAM. In shadow display modes (modes 128 to l35) BASIC or a user program is free to use all memory between OSHWM (PAGE) and &7FFF, plus the 12K bytes of sideways (paged) RAM.
The 12K paged RAM is available to the user in any screen mode, shadow or non-shadow.
Serial interface to RS423 standard. The new standard has been designed to be inter-operable with RS232C equipment. Baud rates are software selectable between 75 baud and 19200 baud (guaranteed up to 9600 baud).
An 8-bit input/output port with 2 control bits.
Four analogue input channels. Each channel has an input voltage range of 0V to 1.8V. The conversion time for each channel is 10 milliseconds. The resolution of the ADC chip is 10 bits.
1 MHz buffered extension bus for connection to a variety of external hardware such as a TELETEXT acquisition unit, IEEE 488 interface, WINCHESTER disc drive etc.
Buffered interface for connection via the TUBE to a range of second processors.
Centronics compatible printer interface.
The basic model B+ may have added to it a floppy disc interface using either an 8271 or 1770 controller IC.
Also, a low cost network interface, the Acorn ECONET, may be added.
Finally, a speech upgrade is available using the 5220 speech IC to generate predefined words and sounds through the built-in speaker.
3.2 Power supply
Input voltage 240V AC RMS +/-10%
Input frequency 47-53Hz
+5V output voltage +5V DC +/-0.1V
+5V output current 0.1A minimum
3.5A maximum
+12V output voltage +12V DC +/-10%
+12V output current 1.25A maximum
-5V output voltage -5V DC +/-10%
-5V output current 0.1A maximum
Total output power 35W
3.3 Display outputs
Modulated output (marked UHF out)
Standard 625-line PAL A UHF colour television signal
Channel E36
Vision carrier Nominal 591.25MHz
RF output 1.0 to 2.5mV
6db bandwidth >= 8MHz
RF output impedance 75 ohms
Connector phono
Composite video (marked video out)
Output level Nominal 1V peak to peak
Output impedance Nominal 75 ohms
Option Chrominance information (link selectable) allows composite PAL monitors to be used
Connector BNC
Colour monitor (marked
RGB)
RGB signals TTL type levels
CSYNC signal TTL type level +ve/-ve going (link selectable)
Connector 6-pin DIN
3.4 RS423
Line length 1200m maximum
Input impedance > 4k ohms
Baud rate 19200 maximum
(guaranteed up to 9600)
3.5 Cassette interface
Output impedance Less than 1k ohms
Input impedance Greater than 100k ohms
Output level Nominal 200mV peak to peak, 70mV RMS
Dynamic input range Nominal 50mV to 5V peak to peak, -25 to +15dB
0db = 350mv RMS
Motor control By miniature relay within computer
Contact rating 1A at 24V DC
Baud rate 300 or 1200 baud using standard CUTS tones
(1200 and 2400 Hz tones)
Connector 7-pin DIN
3.6 Analogue to digital converter
Resolution 10 bit
Full scale
input voltage VREF
VREF l. 8V typica1
Accuracy (with
respect to VREF)
full scale error 0.5% typical
zero scale error 0.5% typical
Non-linearity 0.1% typical
Temp coefficient -6mV/degree C typical
Conversion speed 10.0ms per channel typical
Input impedance > 1M ohms
3.7 ECONET
Line voltages 0.25V and 3V typical into 50 ohms
3.8 Centronics compatible printer interface
Data strobe 4µs pulse
3.9 Audio output
Output power 0.5W
Speaker impedance 8 ohms
3.10 Environment
Air temperature
system on 0 to 35 degrees C
system off -20 to 70 degrees C
Humidity
system on 85% relative humidity at 35 degrees C
system off 95% relative humidity at 35 degrees C
Storage conditions
air temperature -20 to 70 degrees C
humidity 95% relative humidity at 55 degrees C
3.11 Dimensions
Height 73mm (including feet)
Width 415mm
Depth 345mm
4 Disassembly and assembly
To service the BBC Microcomputer B Plus, first disconnect the power supply plug from the mains and remove all peripheral connections from the computer.
To disassemble
The lid of the microcomputer case may be removed after undoing four fixing screws, two on the rear panel and two underneath. Take care not to lose the two spire clips pushed onto the case lid, into which the rear fixing screws locate. DO NOT remove the lid with the mains power connected.
Inside the microcomputer are three main sub-assemblies:
The power supply unit, keyboard and the main printed circuit board.
To remove the keyboard, undo the two screws and nuts holding it to the case bottom, taking care to note the positions of the associated washers. Unplug the 17-way keyboard connector and the 2-way loudspeaker connector from the main printed circuit board, and the 10-way serial-ROM connector, if fitted.
The power supply unit is connected to the main circuit board by seven push-on connectors which may be unplugged. Three screws on the underside of the case are undone allowing the unit to be removed. On reassembly, ensure that the same type of screw is used (M3x6mm).
The main printed circuit board can be removed after the two wires to SK2 (composite video BNC socket) have been disconnected. Undo the seven fixing screws and remove the circuit board from the case by sliding it forwards and then lifting it from the rear.
To reassemble
Replace the main printed circuit board by putting the front edge (with connector headers) in first and pulling it forwards as far as possible until the back edge drops in. Be careful not to trap the composite video wire to the BNC connector if this was removed. Replace the
PCB fixing screws.
Reconnect the composite video and its connector.
Reconnect the power supply, being careful to route the wires neatly, and connect the wires (seven) to the push-on connectors on the
PCB, being very careful to get the polarity right.
PCB connectors marked VCC must have a red wire attached (three).
PCB connectors marked 0V must have a black wire attached (three).
The connector marked -5V has the purple wire attached (one).
Replace the keyboard and reconnect the loudspeaker to the main
PCB. Be careful to reconnect the keyboard ribbon socket so that all the pins are engaged; it is easy to displace the connector one pin to right or left. Replace the 10-way serial-ROM connector if fitted. Replace the nuts and bolts holding the keyboard in place.
Make one final check that all reconnections have been made correctly, especially the power supplies which will short circuit if two are reversed.
Replace the lid and press down at the rear whilst tightening the two rear fixing screws. Finally replace the front two fixing screws.
5 Circuit description
This circuit description has been kept as simple as possible as the detailed fault finding section (section 9) should prove to be of more use for servicing. A detailed description is given of those features of the BBC Microcomputer B+ which are new.
5.1 General
The microcomputer uses the 6512 CPU (IC42) which allows more accurate timing of the logic circuitry than did the 6502, see 5.2. The 6512 requires two clock signals at 'MOS' voltage levels, in all other respects it functions in the same way as the 6502.
The computer clocks are derived from a 16MHz crystal controlled oscillator circuit (X1 and half of IC26), and divider circuitry in the video processor ULA (IC53).
The 6512 accesses 31 1/4Kbytes of ROM, 3/4Kbyte of memory mapped input/output, and up to 44Kbytes of RAM. 64Kbytes of RAM are installed on the
PCB, the extra 20Kbytes being used for the screen memory in shadow mode, see 3.1.
The memory mapped I/O is located in pages &FC, &FD, and &FE of the CPU address space.
There are five sideways ROM sockets installed on the
PCB, each capable of taking an 8, 16, or 32Kbyte ROM or
EPROM (ICs 35 44 57 62 68). When used with a 32K ROM, each sideways ROM socket is decoded as two 16K sideways ROM slots. A sixth ROM socket IC71 holds a 32Kbyte ROM which contains the operating system and BASIC. The number of the ROM currently in use is held in the ROM select latch (IC45).
64Kbytes of RAM are installed on the board in eight 64K by 1 bit
DRAM chips, (ICs 55 56 60 61 64 65 66 67). Of this RAM, 32Kbytes are always accessible to the CPU, 12Kbytes can be paged into the sideways (paged) ROM space, and the remaining 20Kbytes are used as screen memory in shadow mode. Both CPU (IC42) and
6845 cathode ray tube controller (IC78) have access to the RAM. Each can access the RAM at full 2MHz clock speed by, interleaving the accesses on alternate phases of the 2MHz clock. The RAM is thus being accessed at 4MHz. The
6845 accessed the RAM sufficiently to perform the refresh function.
Screen display is provided through the
6845 (IC78), video processor (IC53), and various encoding circuits. Three display outputs are available:
RGB consists of CSYNC and RED GREEN BLUE at TTL voltage levels. Each colour is either on, off, or flashing, giving sixteen displayable colour effects, i.e. eight static colours and eight flashing colours.
VIDEO output is a summation of
RGB to give a grey scale (luminance only). If link S26 is made the chrominance component (colour information) is added to the VIDEO output.
UHF output is obtained by mixing luminance, chrominance and SYNC signals, and then feeding the result to a UHF modulator.
Serial input/output is provided by the cassette port and RS423 port. Both are controlled by the 6850 asynchronous communications interface adapter (IC82) and a ULA called the serial processor (IC85).
Analogue input is fed to the four-channel 10 bit ADC chip (IC84).
A local area network facility is provided by the ECONET circuitry, centered on the 68B54 advanced data-link controller (IC81).
Two build options are available for the floppy disc circuitry. One is based on the 8271 floppy disc controller (IC15) as used on all BBC Microcomputers issues 1 to 7. The second option is based on the 1770 floppy disc controller (IC16). Same components are common to both options. The 1770 operates in either single density (FM) or double density (MFM) mode, and includes a data separator and disc speed decision logic. The 1770 controller interface is therefore simpler than the 8271 controller interface. ICs 1, 2, 3, 4, and 9 are not required with a 1770.
The
Centronics compatible printer interface is based on half (the A port) of a 6522 versatile interface adapter (IC10). IC5 buffers data sent to the printer.
The User Port is connected directly to the B port of the same 6522 (IC10).
The 1MHz extension bus is a fully buffered interface to the CPU, operating with 1µs transfer cycles. The bus appears as a 512 byte address block in the processor I/O space at pages &FC and &FD.
The TUBE interface provides buffered address and data lines for connection to a second processor. The TUBE itself is a fast parallel bidirectional FIFO and is resident in the 2nd processor unit.
The keyboard is read through half (the A port) of a 6522 versatile interface adapter (IC20).
Sound is produced by the 76489 (IC38), a four-channel sound generator chip.
Speech may be generated using an optional 5220 speech processor (IC29) and 6100 word PHROM (IC37).
5.2 CPU timing
A 16MHz crystal controlled oscillator (X1 and half of IC26) generates clock pulses which are divided by circuitry within the video processor ULA (IC53). Pins 4, 5, 6, and 7 of the video processor provide 1MHz, 2MHz, 4MHz, and 8MHz outputs respectively. 8MHz, 4MHz and 2MHz are used to generate RAS and CAS for the DRAMs, and 6MHz for the TELETEXT chip IC59. 2MHz is used to generate the main system clock, 2E. 1MHz is used directly by the TELETEXT chip, and also in conjunction with 2MHz to generate the phase shifted 1MHz system clock, 1E from IC25.
The CPU is normally clocked at 2MHz. The 6512 (IC42) requires a two phase non-overlapping clock on inputs phi1 (pin 3) and phi2 (pin 37), see figure 1.
2M
Ø1
Ø2
Figure 1 Non-overlapping clock inputs phi1 and phi2
Phi1 and phi2 are generated by IC33, two gates of which are used to build an R-S latch. Not2M from IC26 is used to set and reset the R-S latch which toggles at 2MHz unless a third gate from IC33 blocks the not2M signal. During 2MHz operation the phi2 clock corresponds to not2M, the inverse of 2M from the video processor.
When accessing slow devices (1MHz extension bus, ADC, VIAs, 6845, ACIA, and serial processor) the clock is stretched to give a pseudo 1MHz cycle. The system 1MHz clock, 1E, is generated in half of IC25 from the 1MHz and 2MHz outputs of the video processor. The other half of IC 25 is used to synchronise the transition from 2MHz to 1MHz clocking. Each 1 MHz peripheral select line is connected to an input of NAND gate IC41. If any input of this NAND gate is taken to logic 0 then a 1MHz CPU cycle will occur. For 1MHz cycles phi2 is held at logic 1 until the 1E signal is synchronised. The cycle ends with both phi2 and 1E falling together.
There are two ways in which the transition from 2MHz to 1MHz takes place depending on which phase 1E was on when the request was received from IC41, see figure 2.
2M
2E
1E
sync 1M
Ø2
Figure 2 2MHz to 1MHz transition
5.3 Reset circuitry
The system has two reset circuits, one is a general reset from a 555 timer (IC43), the other is an RC network which just resets the system VIA (IC20) on power-up. This allows the software to detect the difference between a power-on reset and a BREAK key reset. The keyboard BREAK key connects via S10 (a PCB made link) to the 555 timer. The 555 generates reset pulse RS which is inverted to give the CPU notRS signal.
5.4 Address decoding and memory
Figure 3 shows the memory map.
FFFF FF00 |
|
|
|
|
O/S |
C000 FC00 |
|
|
|
|
I/O |
|
|
|
|
|
OPERATING SYSTEM |
|
4K BACKGROUND ROM |
|
16K |
|
BASIC |
8000 8000 |
12K |
|
|||
3000 B000 3000 0E00 |
20K |
|
|
|
NORMAL |
|
|||||
|
|||||
0000 |
WORKSPACE |
||||
Figure 3 Memory map
At the heart of the memory selection is the programmable array logic (PAL) chip IC36. It selects which screen RAM is in use (normal or shadow); it controls the sideways ROM select latch IC45; it selects the paged RAM.
5.4.1 ROM operation
Any ROM socket on the
PCB can either hold an 8K, 16K or 32K BYTE device. 8K or 16K IC's are paged into the memory map from &8000-&9FFF or from &8000-&BFFF respectively, a 32K device provides two 16K banks of memory paged into the memory map from &8000-&BFFF. The extra address line A14 (QA, from IC45) required by 32K devices is available to each ROM slot when the appropriate molex link is altered. The ROM socket IC numbers, their corresponding ROM select numbers and their corresponding link numbers are shown in figure 4.
IC No ROM Nos Link No Notes
IC35 2/3 S9 Molex link made W as standard for 8K/16K use
IC44 4/5 S11 " " "
IC57 6/7 S12 " " "
IC62 8/9 S15 " " "
IC68 10/11 S18 " " "
IC71 0/1 or S19
PCB cuttable link made E as standard for 32K
14/15 (16K operating system and I/O and 16K BASIC)
Figure 4 ROM socket IC numbers, ROM numbers, and device selection link numbers
As can be seen from figure 4, ROM numbers range from 0 to 15. ROMs are prioritised, the highest ROM number language and filing system will be selected after a 'hard' reset. 15 has the highest priority, 0 the lowest. So if two or more sideways ROMs are language ROMs, then the computer will start up in the language in the highest number ROM slot. Similarly for filing system ROMs.
IC35, 44, 57, 62, and 68 we shall call "user ROMs". Each user ROM socket is functionally identical and can contain language or service ROMs. IC71 we shall call the "system ROM".
The system ROM contains the operating system. The operating system is always in the memory map from &C000-&FFFF and must always be fitted in IC71. As standard, the computer comes with a 32K ROM for IC71. It contains the operating system and the BASIC language. For this reason link S19 is hard wired East in the 32K position.
The BASIC part of the system ROM occupies one of four sideways ROM numbers. As standard, any call made to ROM 14 or 15 selects BASIC, and any call to ROM 0 or 1 is ignored. Hence BASIC occupies the highest priority ROM slot and the computer will start up in BASIC. If molex link S13 is moved from South to North then any call made to ROM 0 or 1 will select BASIC, and any call to ROM 14 or 15 will be ignored. This allows the user to select an alternative language at power-on (the language entered at start-up will be the one with the highest socket number when more than one language ROM is fitted).
Address decoding is carried out by the PAL (IC36) and this then selects either the operating system (if the address is in the range &C000-&FFFF) or the current sideways ROM (if the address is in the range &8000-&BFFF). Part of IC40 disables the ROM output drivers when an I/O address occurs (&FC00-&FEFF).
The currently selected ROM number (0-15) is held in the ROM select latch IC45. The ROM select latch is mapped into the memory at address &FE30 via the PAL IC36. When writing to this address, the four data lines D0-D3 provide the ROM number which is latched into IC45, see also 5.4.2.
When the PAL decodes an address from &8000-&BFFF, IC36 pin 18 goes low and enables IC46. IC46 is a three line to eight line decoder which selects the particular IC socket allocated to the ROM number, in IC45. The least significant bit held in IC45 is fed to the relevant ROM socket only if the link for that socket is made E for a 32K device. The correct half of the 32K device is then selected to be placed in the memory map.
5.4.2 Paged RAM operation
The 12K paged RAM is selected with a ROM number between 128 and 255 (D7 set). The top bit of the data bus D7 is available to the PAL IC36. Writing to the ROM select latch at address &FE30 as described in 5.4.1, will save D7 in the PAL. D0-D3 are stored as normal in IC45. If D7 is set (logic 1) then the PAL selects the 12K paged RAM when the CPU address is in the range &8000 to &AFFF. If the ROM selected by D0-D3 is present then the top 4K of that ROM will also appear in the memory map, above the 12K paged RAM, from &B000-&BFFF. As ROM 0 is not allocated as standard (it is BASIC if S13 is changed), writing 128 to the ROM select latch will merely place the 12K paged RAM into the memory map and &B000-&BFFF will be vacant.
5.4.3 RAM access
There is 64K of installed RAM.
RAM access is dependent on whether the computer is in normal mode or shadow mode, and the differences are shown in Figure 5.
64K |
|
|
|
|
PAL |
|
|
||||
|
|
|
|
|
CPUSEL =1 |
|
CPUSEL =0 |
|
|
||
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
44K NORMAL RAM |
|
|
|
20K SHADOW RAM |
|
|
44K NORMAL RAM |
|
|
|
|
|
||||||||||
0 |
|
|
|
|
|
|
|
|
|||
|
|||||||||||
32K
Figure 5 RAM access in normal and shadow modes
In normal mode the RAM can be thought of as 44K from address &0000-&AFFF. The top 12K of this RAM from address &8000-&AFFF is paged into the memory map when required in place of the bottom 12K of the sideways ROM space, see 5.4.2. The remaining 20K of RAM is set aside for the shadow screen memory, while it always exists, it is not available to the system in normal mode. The bank of 44K RAM we shall call "normal RAM". In normal mode, VDUSEL (IC36 pin 17) is always zero.
Any code executing anywhere within normal RAM in normal mode will always access normal RAM, it cannot access shadow RAM.
In shadow mode the RAM can be thought of as 44K from address &0000-&AFFF, plus a parallel bank of 20K RAM from address &3000-&7FFF which we shall call "shadow RAM". As in normal mode, the top 12K of normal RAM is paged into the memory when required. In the address range &3000-&7FFF the PAL (IC36) is able to switch between shadow RAM and normal RAM. It selects access to the shadow memory if a) shadow mode is on b) it detects a VDU driver and c) the operand address is between &3000 and &7FFF, the part of the memory map used by the screen. Otherwise it selects access to normal RAM. The machines logic is set to shadow mode when logic 1 is written to D7 at address &FE34, this causes pin 17 (VDUSEL) to go high. &FE34 is the address of a register in the PAL and when D7 is set any screen access through the VDU drivers will cause the PAL to switch in the shadow memory by making pin 12 (CPUSEL) high. In shadow mode, VDUSEL is always set, and CPUSEL is low to access normal RAM and high to access shadow RAM.
When the paged RAM is selected in shadow mode, the top 4K, &A000 to &AFFF, is programmed by the PAL (IC36) to have the attributes of VDU drivers.
Any code executing between &0000-&9FFF in shadow mode will always access normal RAM.
Any code executing from sideways RAM between &A000-&AFFF will access the shadow RAN (if selected) when the operand address is between &3000-&7FFF. This special attribute is not available to any other sideways memory, ROM or RAM.
5.4.4 RAM circuitry
The 64K installed RAM is provided by eight 64K by 1 dynamic memory devices ICs 55, 56, 60, 61, 64, 65, 66, and 67. Figure 6 shows the RAM timing diagram.
2E
RAS
CAS
CPU VDU CPU
Figure 6 RAM timing diagram
The RAM control circuit is designed to work with either 128 or 256 refresh cycle
DRAMs, refresh being provided by the
6845 CRTC (IC78) in conjunction with two ex-OR gates of IC63 and an AND gate of IC34.
The RAM is accessed at 4MHz, the CPU and VDU each having 2MHz access.
The address multiplexers for the VDU cycle are ICs 72, 73, 74, and 75. Various combinations of the inputs of these ICs are used depending on the screen mode in use. In particular, TELETEXT mode 7, with its own character generator (IC59) is markedly different from the other seven bit-mapped modes 0-6.
The address multiplexers for the CPU cycle are ICs 50 and 51.
RAM is working (being addressed and strobed) the whole time., both during CPU and VDU phases, even when not required (except for the purpose of refresh). But data to or from the RAM is only available to the CPU, when the data buffer IC49 is enabled. This occurs when any input to the NAND gate in half of IC40 goes low, that is when A15 is low (address between &0000-&7FFF) or if the paged RAM signal from IC36 is low (address between &8000-&AFFF and paged RAM selected), or if the video processor (VIDPROC) is enabled (address &FE20). RAM is disabled when the VIDPROC is written to, by holding notCAS at logic 1 (see IC23).
5.5 Disc interface
There are two floppy disc interfaces which can be fitted to the PCB, based on either the 8271 floppy disc controller for FM only, or the 1770 floppy disc controller for FM and MFM.
5.5.1 8271 FDC
Two open collector buffer ICs are used to drive the disc unit. A 7416 (hex inverter, IC8) is used to invert the "true" control signals output by the controller IC15. Two gates from a 7438 (quad NAND gate, IC7) generate the two drive select signals by combining the controller's drive select lines with the load head signal (used as a motor control line).
Each data pulse from the drive triggers/retriggers a monostable pulse generator IC1. The pulse clears an R-S latch formed by two cross-coupled NAND gates (IC9), and clears the bit interval timer formed by two divide by sixteen circuits (IC2) and a NAND gate (IC9). If the bit interval exceeds the time determined by the bit intervaltimer then the latch will be set (DW=1). The 8271 monitors the latch (the data window) and the read data pulses to decode the serial data stream.
If the latch is reset (DW = 0) when a data pulse occurs, the 8271 interprets the bit value as logic 1; conversely if DW = 1 then the data bit is a logic 0. Logic 0 bits are encoded as 8µs between RD pulses, logic 1s as 4µs, and each bit interval is 8µs.
The bit interval timer is designed to detect an interval of approx. 6.5µs.
Disc speed is measured by timing the interval between index pulses, which are nominally 200ms apart. One interval timer IC4 is used for both RDY0 and RDY1. 16/13 MHz (1.2307MHz) is used to clock a binary counter (IC4). When all drives are off, the MOTOR signal will be high (off). Motor off forces both stages of IC3 to predefined states, IC3 pin 13 is high and IC3 pin 2 (notRDY) is high. A drive is turned on when MOTOR goes low. IC3 can now be clocked by index pulses and so detect the state of the digital timer IC4.
If IC4 pin 11 goes high then the interval between index pulses is greater than 213ms (2^18*812.5ns), and the disc speed is too slow. If IC4 pin 11 is still at logic 0 when an index pulse occurs then the disc speed is taken to be almost right, so that after one additional disc revolution the speed can be assumed within working limits. IC3 pin 13 is clocked low if IC4 pin 11 is low when an index pulse occurs. If IC3 pin 3 is still low at the next index pulse then IC3 pin 2 will go low, indicating that the drive is ready. Diode D1 and resistor R2 OR the MOTOR signal and the state of IC4 pin 11. The OR function means that whenever IC4 pin 11 goes high it will set IC3 pin 13, and the RDY generation sequence is returned to the beginning. Resetting IC3 by IC4 pin 11 avoids a false RDY if the drive is very slow, when IC4 pin 11 might go high then low between two index pulses.
Communication between the 8271 disc controller and the microprocessor occurs at two levels:
Commands to the disc controller are made by normal program controlled accesses to the I/O space between addresses &FE80 and &FE83.
Bytes of data transferred between the disc and the controller are processed using an NMI interrupt routine which demands immediate action from the CPU. The interrupt program code accesses the 8271 at address &FE84; this address is for DACK controlled transfers. When a DACK controlled transfer is required the 8271 generates an interrupt by setting pin 11 high (of IC15). The interrupt request is inverted by IC7, an open collector NAND gate, to become notNMI. NotNMI is a wire NOR signal which passes directly to the CPU notNMI input (IC42 pin 6) via an AND gate (IC34).
Address decoding for the disc controller is done by three ICs.
IC22 pin 8 goes low when the CPU address is greater than &FC00, and so enables the I/O decoding logic. IC21 generates the notFDC signal which is low for address values &FE80 to &FE9F. The final decode is by IC28 which splits the notFDC space into blocks of four using the A2 address. IC28 pin 12 is low for &FE80 to &FE83 which is the notCE address for the 8271 disc controller. NotDACK is low for &FE84 to &FE87. Pin 15 of IC28 is he1d permanently low (link S7 West) as 8271 interface timing is controlled by not2M through the notR and notW signals (from IC27).
5.5.2 1770 FDC
The 1770 is expected to be the standard disc interface. A 1770 operates in either single density (FM) or double density (MFM) mode, and has data separator and disc speed decision logic built in. A much simpler disc interface results: ICs 1, 2, 3, 4 and 9 are not needed. No drive select logic is incorporated in a 1770 so IC17 is fitted for this function. IC17 also latches two control signals which are used to select between FM and MFM operation and to reset the 1770, both under program control.
The control register IC17 is a write only device which occupies the address space &FE80 to &FE83. IC23 gates the decoded address signal with notW (IC27 pin 6) to form the control register clock.
All 1770 registers are addressed in the range &FE84 to &FE87.
It can be seen that the 1770 controller and the 8271 controller address space has been swapped. This is to allow the disc system software to distinguish between the two devices.
Two interrupt signals come from a 1770, pins 27 and 28. The two interrupts are inverted and wire NORed on to the notNMI line by two parts of IC7 (quad NAND gate). Link S8 selects between the single interrupt of an 8271 and dual interrupt of a 1770. When a 1770 is fitted S8 must be made. For the 1770 option link S7 is made East, this incorporates not2M into the chip select signals and so defines the timing of data transfers between the disc controller and the CPU. Link S5 is available to allow program controlled suppression of 1770 disc controller interrupts (IC17 is not present when the 8271 is fitted). The disable function is not used at present so S5 is not fitted.
5.6 Display circuitry
Three display outputs are provided – RGB, composite video, and UHF.
5.6.1 RGB
Red, green and blue signals are produced by the video processor and are then buffered by Q1, Q2, and Q3 to be fed to the DIN socket (SK3) at TTL type levels. The fourth signal required at the RGB output is a composite SYNC (CSYNC) generated from horizontal sync and vertical sync of the 6845. CSYNC polarity can be altered using link S27. The 0V and +5V power supply also appears on SK3.
5.6.2 Composite video
Composite video is a summation of the three primaries (red green and blue) to give a grey scale, mixed with negative CSYNC. The order from darkest to lightest is: black, blue, red, green, magenta, cyan, yellow, white. The grey scale is set by the resistor values R101, R104, and R108. These feed Q8 which produces a 1V peak to peak signal on BNC connector SK2. The chroma component described in 5.6.3 may be added to the composite video by making link S26. The voltage ratio of chroma to luminance is defined by C48.
5.6.3 UHF
Red green and blue are summed by resistors R82, R84, and R93 and fed into Q6 to create a grey scaled luminance (or luma) signal. Diodes D12, D13, and D14 boost the luminance level for colours to compress the grey scale. Resistors R107 and R138 mix the luma and negative CSYNC respectively while R139 and R146 trim the DC level of the "video" waveform fed to the UHF modulator. Chroma is added through C49. The modulator generates an amplitude modulated UHF signal on TV channel E36 (591.25MHz).
The chroma signal is an amplitude and phase modulated 4.4336MHz simulated sine wave which is added to the video signal. For neutral colours, white/black/grey, the chroma amplitude is zero. For other colours the phase of the chroma signal determines the colour while the chroma amplitude fixes the colour strength. The chroma phase is measured, in the TV, against a reference set by locking to the (average) colour burst. A 17,734,475Hz (+/-100Hz) oscillator is used to generate the colour subcarrier master clock. VC1 allows adjustment of the clock frequency. Two D type registers form a ring counter which generates two phase shifted 4.4336MHz signals (IC79 pins 6 and 9). All chroma signals are derived by mixing combinations of the two master chroma signals or their inverse with a bank of ex-OR gates. For PAL (Phase Alternation by Line) the chroma signal reference phase is shifted 90 degrees on alternate lines. An exclusive-OR gate (IC83) driven from half of IC69 modifies one of the ring counter outputs to cause the required phase alternation.
For NTSC operation, link S28 can be changed to give a constant reference phase (IC83 pin 13 to 0v) – R92 must be removed for NTSC, and the crystal X2 must be 4 times the colour carrier frequency of the NTSC broadcast standard (e.g. 14.318MHz for USA).
The chroma waveform phase and amplitude are selected by the red green and blue (
RGB) signals from the video processor.
RGB controls the six ex-OR gates (IC86 and IC83) to direct the required phase(s) of 4.4336MHz to the NAND gate array (IC87 and IC90) and to enable the appropriate NAND gates. Resistors R85 to R92 mix the NAND gate outputs to form a single chroma signal, including the colour burst. R86 and R89 are used to match the DC level from the resistor mixing network for all colours, but not the colour burst. A crude low Q tuned circuit formed by L1 and C40 filters the chroma signal before it is buffered with the emitter follower Q9. R114 and R120 bias Q9 and also offer a suitable termination to the filter. Q9 then drives the signal mixing point to form the complete colour video signal used to drive the UHF modulator. The impedance of C49 (at 4.4336MHz) fixes the voltage ratio of chroma to luma in the modulator drive signal. C48 serves the same purpose, when link S26 is made, in mixing chroma into the video waveform available at SK2.
5.7 Centronics compatible printer interface
The computer can drive a Centronics compatible printer through IC10, a 6522 VIA. Port A of the VIA is configured as an 8-bit output port which is buffered by IC5 and fed to PL9. Printer strobe pulses are generated by a program sequence which toggles CA2 (IC10 pin 39) high-low-high. Strobe pulses are typically 4µs wide. ACK from the printer is connected to CA1 (IC10 pin 40). ACK is pulsed low for approximately 5µs by the printer when it is ready for the next character/byte transfer.
5.8 User port
Port B of IC10 offers eight individually programmable input/output lines, and two programmable control lines, connecting to PL10.
5.9 1MHz extension bus
The 1MHz bus is a fully buffered interface to the CPU via PL11, which operates with 1µs transfer cycles. IC12 (bi-directional buffer) is enabled when either FRED or JIM is accessed (pages &FC and &FD). These two pages are decoded by IC22 and IC28, with signals notFRED and not JIM appearing on pins 4 and 5 respectively of IC28. When either notFRED or not JIM goes low, the 1MHz bus enable goes low (IC34 pin11), and takes low an input of the NAND gate IC41 thus causing a 1MHz CPU cycle.
NotFRED (IC28 pin 4) and notJIM (IC28 pin 5), along with R/notW (IC24 pin 10) and 1MHz bus enable (IC34 pin 11) are synchronised to the 1 MHz system clock (1M) by latching them in IC32. This ensures that no glitches occur on the 1MHz bus interface.
5.10 TUBE interface
The TUBE interface connects to a second processor via PL12. The signals present are the eight data lines, five address lines A0 to A4, R/notW, 2E, notRS and notIRQ. The data lines are buffered by IC14, and the address lines, R/notW and 2E are buffered by IC13. The data buffer IC14 is enabled when a TUBE address (&FEE0-&FEFF) is decoded by IC21, this enable signal (notTUBE) being fed also to the TUBE connector, PL12.
R11 is fitted so the computer OS can detect when there is no second processor present (or powered on).
5.11 ECONET
ECONET is based around the 68B54 (IC81) advanced data link controller. IC81 performs the conversions between serial and parallel data, and generates the interrupt requests which are connected to NMI. Each byte transfer between network and CPU is requested by an NMI. Interrupts can be disabled by making pin 4 IC23 low thereby setting the D-type (half of IC69), which is achieved by a read of &FE18. Reading this address returns the station ID number which is set up on the links S23. Interrupts are enabled when pin 2 IC69 goes low (a read of &FE20), which, when clocked by not2E, resets the D-type.
Transmit data from the 68B54 is fed to a differential line driver circuit IC91, and then through SK7 on to the twisted pair network cable. The differential drive voltages are, typically, 0.25V and 3V. A monostable (half of IC88) is used to time-out the ECONET line driver by taking pin 9 IC91 low after approximately 4.5s (longer than the time required to transmit a maximum length data packet). This is designed to prevent a single computer holding its driver on and thereby bringing the whole network down.
Receive data is decoded by a comparator circuit IC92 and fed into the 68B54. IC93, the collision detect circuitry, is not fitted because the software protocols should prevent any collision. Before transmission, the line is sampled to see if it is in use. If it is, the transmission is held up until a certain time after the line is first free again. This time is dependent on the station ID and so will be different for every station on the line. When required collision detect may be installed by fitting components as shown on the circuit diagram, and breaking the link S29, a PCS copper link.
5.12 Cassette and RS423 ports
For both the cassette (SK5) and RS423 (SK4) interfaces, a 6850 asynchronous communications interface adaptor (ACIA) IC82 is used to buffer and serialise or deserialise the data. The serial processor IC85 contains two programmable baud rate generators, a cassette data/clock separator, switching to select either RS423 or cassette operations, and also a circuit to synthesize a sinewave to be fed out to the cassette recorder.
Note that the receive bit rate for cassette operations is derived from the FSK signal not from the serial processor control register bits used when RS423 operation is selected.
IC18 divides the 16MHz clock signal by 13 (1.23 MHz) and this signal is divided further within the serial processor to produce the synthesized 2400/1200Hz cassette record signal, and the bit rate clocks. Automatic motor control of an audio cassette recorder is achieved by using a small relay driven by transistor Q7 from the serial processor.
R66 and C30 provide the necessary timing elements for delay between receiving the high tone run-in signal and asserting the data carrier detect signal to the 6850.
The signal coming from the cassette recorder is buffered, filtered and shaped by three stages of the LM324 amplifier IC89.
The RS423 data in and data out signals and the request to send output RTS and clear to send input CTS signals are interfaced by ICs 94 and 95 which translate between TTL and standard RS423 signal levels +5V and -5V.
RS423 signals are compatible with the RS232 signals common in computer related equipment.
Selection of the cassette or RS423 for input and output is by bit 6 of the serial processor control register, bit 7 is for cassette motor control. Bits 0 to 2 control the transmit bit rate, while bits 3 to 5 set the RS423 receive bit rate.
5.13 Analogue to digital converter
The A to D circuit is based on a uPD7002 IC84, which can accept up to four analogue inputs, from SK6. The voltage reference is set by three silicon diodes, D9, D10, and D11, which gives a typical full scale voltage of 1.8V. When a conversion is complete, the CPU is interrupted via CB1 of the 6522 (IC20 pin 18) which generates an IRQ (IC20 pin 21).
5.14 Audio circuitry
IC38 is a four-channel sound generator which can be programmed to vary the frequency and volume of three independent tone generators and the amplitude of a single noise generator. The sound signal is DC "restored" by mixing in a signal derived from the sound envelope. An inverting peak detector (IC47 D4 C15 etc.) derives the inverted sound envelope which is then summed with the sound signal in the ratio of 2:1. Part of IC47 forms a virtual earth summing amplifier which mixes the sound, its envelope, the external audio input and an optional speech signal into one audio channel. The audio is then filtered through a second order low pass filter (approximately 7kHz bandwidth) and applied to the volume control (optional) before final amplification by IC77 an LM386. IC77 drives the internal keyboard mounted 8 ohm speaker via PL15. Plug S20 allows fitting of a remote volume control, when no volume control is fitted a shunt is required on S20 (south) to enable the audio.
The audio output of the optional speech system is filtered by an operational amplifier second order filter (cut-off frequency of 7kHz) before mixing in with the other audio signals. Speech is generated by an optional TMS5220 with TMS6100 (or equivalent) vocabulary "PHROM".
5.15 Keyboard
The keyboard circuit is given in figure 9.6 of the Appendix. The keyboard connects to the main
PCB via PL13.
A 1MHz clock signal 1E is fed to a 74LS163 (IC1 on keyboard) binary counter, the outputs of which are decoded by a 7445 (IC3 on keyboard) decoder driver circuit. These outputs drive the rows of the keyboard matrix, each row being driven in turn. If any key is depressed, an 8 input NAND (IC4 on keyboard) will produce an output when that row is strobed and this will interrupt the CPU through line CA2, pin 39 of IC20 on the main computer board. The interrupt tells the computer to enter the key reading software. In order to discover which key was pressed, the CPU loads directly into the 74LS163 (IC1 on keyboard) the address of a key matrix row, allowing it to interrogate each row in turn. Also, the CPU drives the 74LS251 data selector (IC2 on keyboard) with the 'column address' of a single key on the selected row. In this way, the processor can interrogate each individual key in turn until it discovers which one was depressed and caused the interrupt. Once read, the keyboard assumes its free running mode.
6 Upgrading the PCB
The following section gives instructions for adding extra hardware to upgrade the
PCB for disc, ECONET, and speech. Dealers and service centers performing these upgrades must also conform to upgrade procedures and requirements as notified by their supplier, and should refer to any available information updates for latest details.
In the following section, items marked * may already be fitted to the board.
All ICs are inserted with their pin 1 facing the back of the computer.
6.1 1770 disc option
FM or MFM 5 1/4 inch floppy disc interface.
i) The following parts are required:
IC7 7438 (must not be 74LS38)
IC8 7416 or 7406
IC16 1770
IC17 74LS174
*R1 150R
*R5 150R
*R6 150R
*R7 150R
*R8 150R
*R14 3k3
The appropriate filing system ROM
ii) Insert the ICs listed above into the sockets which should be provided on the main circuit board. If any sockets are missing then solder in the correct DIL socket for that IC. Note: IC16 uses two 14-pin SIL sockets.
iii) Except on early boards, the resistors listed above will already be in position on the
PCB. Check each one, and solder in any which are missing.
iv) Insert the filing system ROM into a vacant sideways ROM socket (IC 35, 44, 57, 62, or 68).
v) Make link S7 East with a shunt (probably already in this position), or tinned copper wire if molex pins not fitted.
vi) Make link S8 with a shunt (probably already in this position), or tinned copper wire if molex pins not fitted.
vii) Test using a PORT tester.
Note: the 1770 disc upgrade is usually carried out without soldering.
6.2 8271 disc option
i) The following parts are required:
IC1 74LS123
IC2 74LS393
IC3 4013B
IC4 4521B
IC7 7438 (must not be 74LS38)
IC8 7416 or 7406
IC15 8271
*R1 150 R
*R2 10k
*R3 1k
*R5 150R
*R6 150R
*R7 150R
*R8 150R
*R9 3k3
*R10 3k3
*R14 3k3
*C1 1n plate ceramic 2%
*D1 LN4148
*16K ROM (DNFS)
ii) Insert the ICs listed above into the sockets which should be provided on the main circuit board. If any sockets are missing then solder in the correct DIL socket for that IC. Note: IC15 uses two 14-pin SIL sockets.
iii) Except on early boards, the resistors, capacitor and diode listed above will already be in position on the
PCB. Check each one, and solder in any which are missing.
iv) Insert the filing system ROM (DNFS) into a vacant sideways ROM socket (IC 35, 44, 57, 62, or 68).
v) Make link S7 West with a shunt, or tinned copper wire if molex pins not fitted.
vi) Break link S8 by removing shunt (if fitted).
vii) Test using a PORT tester.
Note: If an 8271 disc interface is being fitted as a replacement for an existing 1770 disc interface, the following items must be removed from the
PCB:
IC16 1770
IC17 LS174
Link S8 must be broken.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
IC62 |
|
IC68 |
|
OS/ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
(WEST) |
|
|
|
|
|
|
|||||||
|
|
||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
S7 |
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
IC35 |
|
IC44 |
|
IC57 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
IC9 74LS00 |
|
|
IC3 4013B |
|
|
|
IC4 4521B |
|
R10 |
|
||||||
|
|
|
|
|
|
|
R9 |
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
D1 |
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
R2 |
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
R8, |
6, |
5 |
|
|
|
10k |
|
|
|
|
|
IC2 74LS393 |
|
|||
|
|
|
|
|
|
IC15 8271 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
R1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
R14 |
|
|
|
IC1 74LS123 |
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
R7 |
|
|
|
|
C1 |
|
|
|
|
|
|
|
|
||||
|
|
||||||||||||||||||||||
|
|
IC8 7416 |
|
IC7 7438 |
|
|
|
|
|
|
R3 |
1n0 |
|
|
|
|
|
|
|
|
|||
|
|||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
1k |
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
PL 8 (34 WAY) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
Figure 6. 8271 Disc Interface components.
6.3 ECONET
Local area network interface
Due to the complexity of this upgrade and the specialised test equipment required, it should only be carried out by ACORN Approved ECONET Service Centers, with the appropriate test equipment. Upgrade procedures and requirements, as notified by suppliers, should also be adhered to and reference should be made to any available information updates for latest details.
i) The following items, from the ECONET Hardware Upgrade Kit, are required to upgrade model B+:
QTY DESCRIPTION CIRCUIT REFERENCE
3 RESISTOR 1K0 0.25W 5% R63,73,148
1 RESISTOR 1K5 0.25W 5% R147
1 RESISTOR 4K7 0.25W 5% R59
4 RESISTOR 10K 0.25W 2% R140,141,142,143
1 RESISTOR 39K 0.25W 5% R64
4 RESISTOR 100K 0.25W 2% R106,110,125,134
1 RESISTOR 220K 0.25W 5% R77
2 RESISTOR 1M5 0.25W 5% R78,79
1 RESISTOR PACK 8 x 22K RP2
1 CAPACITOR 10u 6V3 TANT C57
1 CAPACITOR 47u 10V TANT C37
1 CAPACITOR 2n2 CER PL 2% C26
1 IC 68B54 IC81
1 IC 75159 IC91
1 IC 74LS123 IC88
1 IC 74LS132 IC70
1 IC 74LS244 IC80
1 IC LM319 IC92
1 SOCKET DIN 5 PIN 180 DEGREE SK7
2 CONNECTOR 8 WAY WAFER S23
7 SHUNT FOR S23
2 SOCKET 14 PIN DIL FOR IC91,92
1 SOCKET 28 PIN DIL FOR IC81 (OPTION)
1 CONNECTING LEAD ECONET
1 Current network filing system ROM (e.g. DNFS)
IMPORTANT NOTE: Collision detect circuitry is not included in the model B+ ECONET upgrade. It has been found, following exhaustive tests, that this feature is not required when a BBC Microcomputer is operating within -an ACORN ECONET environment. However, it may be required where an ECONET machine is used with equipment which does not include the ACORN NFS software and provision is made for this circuitry to be fitted to the
PCB. See below.
ii) If collision detect circuitry is to be fitted, the track link at S29 should be cut before proceeding (see below).
iii) Solder the 14 pin DIL sockets into positions IC91 and 92.
iv)Insert ICs 91 and 92 into their sockets.
v) Solder all the remaining ICs, resistors and capacitors into their correct positions on the
PCB. IC81 may be socketed as an option, though this may degrade reliability.
vi) Solder the two 8 way wafer connectors into the
PCB in their correct positions and then push the seven shunts onto all but the North-most pins.
vii) Solder the DIN socket into the
PCB.
viii) Insert the filing system ROM (e.g. DNFS) into a vacant sideways ROM socket. Note that, where a B+ machine is already fitted with the 1770 Disc Interface, a DNFS ROM must be fitted in addition to the l770 DFS ROM already installed.
ix) If collision detect circuitry is required, the additional components given below must be fitted:
QTY DESCRIPTION CIRCUIT REFERENCE
1 RESISTOR 1K0 0.25W 5% R68
4 RESISTOR 56K 0.25W 2% R95,96,98,99
1 RESISTOR 1M5 0.25W 5% R97
1 CRPACITOR l0nF CER PLT C28
1 IC LM319 IC93
2 SOCKET 14 PIN DIL FOR IC93
In addition, the track link at S29 should be cut.
x) In order to complete the ECONET upgrade, the machine must be tested using the approved ACORN ECONET test kit.
6.4 SPEECH.
Speech synthesizer, word PHROM, and serial ROM socket
i) The following parts are required:
IC29 5220
IC37 6100 PHROM
15-way single sided edgecard socket (2 off)
10-way right angle wafer plug
10-way connecting lead with sockets fitted
100n disc ceramic capacitor (2 off)
ROM socket cover
ii) Add components other than ICs listed above to keyboard assembly as shown in figure 7.
10-WAY CONNECTING LEAD WITH SOCKETS
10-WAY RIGHT ANGLE WAFER PLUG
15-WAY SINGLE
SIDED
EDGECARD
SOCKETS
100nDisc
CERAMIC
CAPACITORS
Figure 7 Keyboard assembly
iii) Plug the other end of the ribbon cable into PL14 on the
PCB.
iv) Test for continuity between the following points for each edge connector in turn:
Edge connector pin number 6 7 8 9 10 11 12 13 14 15
IC37 pin number 1 3 4 5 6 7 10 11 13 14
Note: on the edge connector pin 1 is nearest the loudspeaker, thus the polarising key is pin 3, and pins 4 and 5 are empty.
Also check that there are no short circuits between any of the edge connector pins.
v) Insert IC29 and IC37 into their sockets on the
PCB.
vi) Turn the computer on and type:
REPEAT SOUND-1, GET, 0, 0: UNTIL0
and press the RETURN key.
Any key now pressed should cause the system to utter a word or sound.
vii) Adjust VR1 until the speech is at the correct pitch. This can be measured by connecting a frequency meter to pin 3 IC29. Adjust VR1 until the meter reads 160kHz +/-100Hz.
viii) Remove the perforated section from the left of the case lid, fit the ROM socket cover, and reassemble the machine.
ix) Test using a PORT tester.
7 Selection links
This section describes the function of each of the links on the
PCB, the type of link, and its position as standard.
S1
PCB track, made West: West for 5 1/4 disc drive, East for 8".
S2
PCB track, made North: North for 5 1/4" disc drive, South for 8".
S3
PCB track, made South: South for 5 1/4" disc drive, North for 8".
S4
PCB track, made South: South for 5 1/4" disc drive, North for 8".
S5 wire link, not fitted: allows disc filing system to disable NMI. This feature is not supported by current disc software.
S6
PCB track, made South: South for 5 1/4" disc drive, North for 8".
S7 plug, made East: East for 1770 floppy disc controller, West for 8271.
S8 plug, fitted: fitted for 1770 floppy disc controller, removed for 8271.
S9 plug, made West: West for 8K/16K ROM/
EPROM in IC35, East for 32K ROM/
EPROM in IC35.
S10
PCB track, made East: East enables keyboard BREAK key, West forces permanent reset, broken (neither East nor West) disables BREAK key.
S11 plug, made West: West for 8K/16K ROM/
EPROM in IC44, East for 32K ROM/
EPROM in IC44.
S12 plug, made West: West for 8K/16K ROM/
EPROM in IC57, East for 32K ROM/
EPROM in IC57.
S13 plug, made South: South causes BASIC to take high priority ROM numbers 14/15, North causes BASIC to take low priority ROM numbers 0/1.
S14 plug, made North: North gives white on black video, South gives black on white video. Beware monitor performance in the latter configuration.
S15 plug, made West: West for 8K/l6K ROM/
EPROM in IC62, East for 32K ROM/
EPROM in IC62.
S16 – test link not present on issue 2 or later
PCB.
S17
PCB track, made North: North configures 1MHz bus audio for input, South for output.
S18 plug, made West: West for 8K/16K ROM/
EPROM in IC68, East for 32K ROM/
EPROM in IC68.
S19
PCB track, made East: East enables BASIC part of OS/BASIC, West disables BASIC and leaves just the operating system.
S20 plug, made South: South gives full volume on audio. Remove if VR2 fitted.
S21 – optional audio output prior to volume control.
S22 –
S23 eight plugs, seven shunts: ECONET ID number set up as binary number by user. Only fitted if ECONET interface fitted.
S24 wire link, not fitted: optional termination resistor for RS423. Should not be fitted for correct operation of RS423.
S25 wire link, not fitted: optional termination resistor for RS423. Should not be fitted for correct operation of RS423.
S26 wire link, not fitted: made adds chrominance component to composite video output.
S27 plug, made South: South gives negative-going CSYNC for
RGB, North gives positive-going CSYNC.
S28
PCB track, made North: North for PAL video circuitry, South for NTSC. Note: for NTSC operation R92 must be cut out. The modulator may need changing for TVs which cannot receive channel 36.
S29
PCB track, made: made for operating ECONET without collision detect hardware. Collisions are detected by software protocols.
S30
PCB link, made: always made for 6512 CPU.
8 Test equipment
A PORT tester is available for the microcomputer. This is an uprated version of the old FIT tester. It will check the
DRAMs, and all the I/O ports on the microcomputer: disc, printer, user, 1MHz bus, TUBE, UHF, video,
RGB, RS423, cassette, A to D, and ECONET. To use this tester, the microcomputer must at least have the CPU running and the MOS/BASIC ROM working and some of the RAM working.
Full operating instructions are supplied with the equipment.
9 Fault finding
This section goes step by step through fault finding in each section of hardware. It should be studied in conjunction with the circuit diagram and block diagram in the Appendix.
If any part of the machine is suspected of being faulty, the following points should always be checked first:
1 no loose connectors and broken cables
2 no broken or shorting tracks
3 ICs plugged into their sockets correctly
4 power supply working and reaching the components concerned
5 all digital signals are at clean TTL logic levels (greater than 2.4V for 1, less than 0.5V for 0). On timed signals this must be true for the period 150ns before phi2 on read cycles and 300ns before phi2 on write cycles.
The following items of test equipment are required for fault finding:
PORT tester
10A Multimeter
logic probe
20MHz dual beam oscilloscope
TV, composite monitor, colour monitor
cassette player
disc drive
frequency counter
5 ohm 5W resistor
9.1 Switch on
Connect the suspect microcomputer to a UHF TV and an
RGB monitor. Connect the mains supply and switch on both the monitors and the computer. One of the following will happen.
a) There is noise on the monitor screens (no signal from computer). There is no power-on beep sound (there may be a continuous noise), and the LEDs do not light, or light incorrectly.
Results: either power supply is dead, or there is a fault in the heart of the microcomputer.
Follow the sequence of checks shown below.
1 If there is no noise on power-up, and no LEDs light up then check the power supply (see 9.2).
2 If a PET tester is available then use it. The PET tester will work on the B+ providing the CPU is running and it can access the ROM, although it may give strange screen output, and some of the tests will fail. Please refer to the information manual supplied to dealers for details of the operation of the PET tester when used with the B+. If PET will not work at all then either the CPU isn't running or it cannot access the ROM.
3 Check HS and VS signals (pin 39 and pin 40 IC78) using an oscilloscope. HS and VS should be clean TTL voltage levels, HS pulsing every 64µs and VS pulsing every 20ms.
Results: if they are stuck or floating then carry on with the checks be1ow. If they are working then the CPU must have programmed the
6845 and so must have gained access to the OS ROM. Check using PET (see information manual supplied to dealers). If the signals are there but are not pulsing at the correct intervals then look for a data line fault to CRTC.
4 Check that the notRS pin of the CPU (pin 40 IC42) is high when the computer is switched on. It should pulse low on power-up and when the BREAK key is pressed. If it is stuck low then look for shorts or damaged components around the 555.
5 Check that there is activity on the SYNC (pin 7 IC42) and the R/notW (pin 34 IC42) lines of the CPU. If SYNC is stuck then the CPU has stalled, and R/notW won't be working anyway. Check for address and data bus short or open circuit, or a complete failure to select the OS ROM (see 9.5).
6 Check the CPU clocks. Phi1 and phi2 should be as shown in figure 1 (see section 5.2). If not then check the 2M circuitry from the video processor IC53. IC33 pin 3 should be low. If not then check SYNC 1M at pin 8 IC41 which should also be low. If SYNC 1M is high then check IC25. If SYNC 1M is stuck high then find which one of the inputs to IC41 is stuck low. The 1MHz device attached to this input must be checked.
7 Check activity on the CPU address lines. If after a BREAK the activity starts and then stops, this suggests that the CPU cannot read the OS ROM. Check the OS ROM by replacing it with a known good one. Check that it is enabled and that all address lines are present. Check following BREAK that notOE pulses low at 2MHz (inverse of phi2), and notCS goes low and stays low for a time.
8 Check all clocks from video processor 8M 4M 2M 1M, see 9.3.
9 After BREAK check CRTC notCS pin pulses low (pin 25 IC78).
If all the above checks pass then the machine should do more than exhibit the symptoms stated in (a).
b) The screen synchronises (no noise) but there is only a flashing cursor in the top left corner.
Results: usually caused by a keyboard fault.
Check that the keyboard is connected correctly, see 9.9.
c) The banner message appears, but is incorrect or incomplete.
The correct banner message is:
Acorn OS 64K
<filing system>
<language>
>
For example, with a 1770 FM disc filing system and BASIC language the correct banner message is:
Acorn OS 64K
1770 DFS
BASIC
>
Results: the CPU is running and is accessing the OS. Use a PET tester if available (see information manua1 supplied to dealers). If the banner message is fragmented then check the CRTC address lines for shorts. If the message gives the prompt
Language?
where BASIC is fitted in the example above check S13 and also check the Pg latch. Language? cannot occur when it is a badly fitted IC since the OS and the BASIC are in the same ROM. A badly fitted OS/ROM would prevent the machine powering up.
d) The machine does a start-up beep, and the caps lock LED comes on, but there is no display, or no display on the UHF monitor.
Results: the video circuitry is faulty, see 9.7.
e) There is no fault on power-up.
Results: most I/O faults will not stop the computer and display from working. Use a PORT tester to find out which I/O circuit is faulty.
9.2 Power supply
With the power supply turned off, unplug the three black 0V leads and the three red +5V leads and the single purple -5V lead from the
PCB.
Connect a 5 ohm 5W resistor across one pair of red and black leads (a pair that were together on the board) and tape the other leads with insulating tape to stop them shorting. Turn on the power supply and measure the voltage across the resistor using an oscilloscope. The voltage must be in the range 4.9V to 5.1V, with a maximum noise of 50mV peak to peak. WARNING: the resistor will get hot.
Repeat the test with the other two pairs of red and black leads.
Results: if any one pair measures zero or a very low voltage then one of the leads is damaged. If all are out of spec then the power supply unit must be changed.
If the +5V lines are good, leave the resistor in place on the last pair and using the other trace on the oscilloscope measure the -5V voltage. Connect both probes to 0V and superimpose the traces in the center of the CRT. Connect one probe to +5V (across the resistor) and the other to -5V (the purple lead). The two traces should deflect in opposite directions, the -5V being between -4.75V and -5.25V.
When all the voltages are correct, switch off the power supply and reconnect the black leads to the
PCB on the connectors marked 0V.
Set the multimeter to a 10A DC scale and connect it between one of the connectors on the
PCB marked VCC and all three red wires together. Turn on the power supply just long enough to measure the current (any length of time may heat up the
PCB tracks excessively). The board should draw from 1.5 to 2.2A, depending on its upgrade state.
Repeat the test, after turning off the power supply, for each of the three +5V connectors on the
PCB in turn.
Results: if the current at any one connector is zero or very low then look for a broken lead, connector, or
PCB track. If all results are zero then there is either a short circuit and the power supply has cut out (likely) or the whole power network has gone open circuit (unlikely). This can be checked by measuring the +5V voltage across the board. Zero voltage means short circuit, +5V means open circuit.
Replace all the power supply leads in their correct positions, red to VCC, black to 0V, and the purple lead to -5V.
As a final check, measure the voltage across the power supply pins of a few ICs around the board and check that it is in spec.
9.3 Oscillator and divider circuitry
Using the oscilloscope, check that 8MHz, 4MHz, 2MHz, and 1MHz are available from pins 7, 6, 5, and 4 respectively of the video processor IC53.
Results: if these signals are not present then check that 16MHz is available at pin 8 IC53. If it is then replace IC53. If not then check the crystal controlled oscillator circuit formed by half of IC26 and X1.
Check that the CPU has two non-overlapping 2MHz clock inputs on pins 3 (phi1) and 37 (phi2) of IC42, as shown in figure 1.
Check that 1E is available at pin 6 IC25. This signal should be phase shifted in relation to 1M at pin 4 IC53 as shown in figure 8.
1M
1E
Figure 8 1M/1E
9.4 CPU
Test pin 40 IC42 (reset pin) and check that it is high. Press the BREAK key and make sure that pin 40 goes low for a reset and then high again on release.
Results: if pin 40 is stuck low then check for a short circuit on the main
PCB, the keyboard, BREAK key, keyboard connectors or the resistors and capacitors of the 555 reset circuitry. If it is stuck high then check the 555 timer circuit (IC43), the keyboard ribbon cable and connectors, and the BREAK key itself.
Check that notIRQ (pin 4) and R/notW (pin 34) are wobbling. If not then test SYNC (pin 7). If SYNC is stuck either high or low then the processor is stalled.
Results: if CPU is stalled then check that ROMs are plugged in their sockets correctly. Check for address and data bus short or open circuit.
9.5 ROM
If ROM circuitry is not functioning then the CPU will not operate. Check that all ROMs are inserted with all the pins correctly in their sockets.
Use a PET tester if available (see information manual supplied to dealers). If this runs then the CPU is functioning correctly.
If the CPU cannot access the OS, check that the OS ROM is enabled and that all address lines are present. Check following BREAK that notOE pulses low at 2MHz (inverse of phi2), and notCS goes low and stays low for a time. Replace the OS/BASIC ROM with a known good one. Make sure that S19 is made East.
If machine works, but sideways ROM selection is faulty, then run the following program to test the ROM select latch.
10 ROMsel% = &FE30
20 INPUT ROMnumber%
30 DIM P% 100
40 [
50 .start%
60 LDA# ROMnumber%
70 STA ROMsel%
80 RTS
90 ]
100 CALL start%
Run the program and type in a number between 0 and 15 (&0 and &F). Check using a logic probe or oscilloscope that the binary representation of this number appears on pins 11 (most significant), 12, 13, and 14 (least significant) of IC45.
Results: if the ROM numbers are not getting through to the ROM latch then alter line 80 of the program to
80 JMP start%
and re-run the program.
Check with an oscilloscope that notPGLD from pin 13 IC36 is wobbling. If not then check for shorted track. If notPGLD is working then replace IC45.
If ROM latch contains correct ROM number but sideways ROMs still do not work then check decoder IC46.
9.6 DRAMs
Use a PORT tester to carry out a RAM check.
Check that RAS and CAS (pins 4 and 15 respectively of the eight
DRAM ICs) are wobbling.
Results: if RAS is stalled low then the
DRAM ICs may be destroyed. Check the circuitry for generating RAS and CAS (the video processor IC53 8M, 4M, and 2M, half of IC31, and various gates). Check that RAS and CAS timing is as shown in figure 6.
Check that RAM data lines are wobbling.
Check that the data bus buffer is being enabled, pin 19 IC49.
9.7 Video
Look at the displays from the three monitors (UHF, video, and
RGB) and see which of the following, (a), (b), (c), or (d) best describes them.
a) None of the monitors operate.
Results: there are incorrect signals coming from the video processor. Replace the video processor IC53.
Run the following program and check that video processor is being selected (pin 3 IC53 is wobbling).
10 vidproc% = &FE20
20 DIM P% 100
30 [
40 . start%
50 STA vidproc%
60 JMP start%
70 ]
80 CALL start%
b) The
RGB works but the UHF doesn't. Test the UHF modulator input voltage using an oscilloscope. Set the oscilloscope to 50mV per division, 10 microseconds per division, auto trigger, and attach the probe to the wire running through the white plastic boss in the center of the left side of the modulator.
Press the BREAK key and check that the PAL voltage waveform looks something like figure 9.
Figure 9. Black PAL voltage waveform
Type in the following:
COLOUR 129 : CLS
and press RETURN
The waveform should now look something like figure 10.
Figure 10 White PAL voltage waveform
Results: if the two waveforms are correct and the UHF monitor does not give a display then the UHF modulator is faulty and should be replaced.
If the colour burst part of the waveforms is missing then the fault lies in the chrominance circuitry, see (c).
If any other part of the waveforms is incorrect, make link S26 temporarily and test the composite video output with an oscilloscope. The waveforms should be similar to those indicated in figures 9 and 10, but of reduced amplitude (1V peak to peak).
If the composite output waveforms are good with link S26 made (including colour burst), but the UHF output does not work, then the fault lies in the UHF luminance circuitry (Q6, D12, D13, D14, C36 and associated resistors). Check that diodes D12, D13, and D14 are inserted the correct way round (the
PCB is marked +).
If the video output waveforms are bad then the video luminance circuitry (Q8 and associated resistors) may be faulty, and possibly chrominance circuitry also, see (c).
A composite colour monitor can be used to test the video output with link S26 made. If the composite colour monitor works in black and white only then the chrominance circuitry is faulty, see (c).
c)
RGB works; UHF works in black and white only.
Results: the chrominance circuitry is faulty. Test pin 3 of IC87 with a frequency counter. The measured frequency must be 17.7345MHz +/-400Hz, and can be adjusted using VC1. If there is no signal on pin 3 IC87 then check the oscillator circuit formed by X2, Q10 and associated components.
IC79 is a 74S74. A 74LS74 in this position can cause the circuit to fail. Check that there are signals from pins 9 and 6 of IC79 (4.4336MHz) and also a signal from pin 9 IC69 (7.7kHz approximately).
Check that L1 has not gone open circuit and that C49 has not failed, and check Q9.
Failing all this check the logic circuit formed by ICs 83, 86, 87, and 90, and resistors R85 to R92.
d) The
RGB picture is distorted.
Results: either the DIN plug is incorrectly fitted to the monitor socket, or CSYNC must be inverted by altering S27.
9.8 Cassette interface and RS423
These two interfaces are examined together because they share two major components, the UART or ACIA IC82 and the serial processor or SERPROC IC85.
If both the cassette interface and RS423 fail (shown up by the PORT tester) then it is likely that the fault is with one of the above ICs or its address decoding.
a) Cassette interface
Use a PORT tester to verify that the cassette interface is faulty.
All tests on the cassette interface must be carried out using a known working cassette recorder and tape. The commonest fault is the user's cassette recorder and the azimuth adjustment should be checked. The tape recorder's volume control should be set for an output of 300mV peak to peak.
Test pin 25 IC85 (the serial processor) and check that 16MHz/13 (812ns period) is arriving at that pin. This signal must be stable and accurate. If not, the divide by 13 circuitry formed by IC18 is faulty.
If the cassette fails to LOAD, look at the following pins while attempting to LOAD:
IC89 pin 8 should show high and low tones of equal amplitude, symmetrical about 0V. If there is a marked displacement then replace IC89.
IC89 pin 14 should be similar to pin 8, with maximum 50mV displacement.
IC89 pin 1 should show a 1.4V peak to peak square wave with an even mark/space ratio. Reduce the volume of the cassette recorder until this is so. Maximum 50mV displacement.
Check that pins 2 and 3 of IC82 are wobbling.
Check that both IC82 and IC85 can be selected by running the following program.
10 acia% = &FE08
20 serproc% = &FE10
30 DIM P% 100
40 [
50 . start%
60 LDA acia%
70 LDA serproc%
80 JMP start%
90 ]
100 CALL start%
Monitor the two chip selects, pin 9 IC82 and pin 9 IC85. These should be wobbling. If one is faulty then check the address decoding IC21 and IC39, and the connections from pin 5 and pin 6 IC39.
If the cassette fails to SAVE, then SAVE a section of ROM and check if there is a synthesized sine-wave signal from IC85 pin 27 of around ???? peak to peak. If not then replace IC85. If there is then replace the LM324 (IC89).
b) RS423
Use a PORT tester to verify that the RS423 is faulty.
One way of checking the operation of the RS423 is to connect the suspect microcomputer to a known working microcomputer via their RS423 ports. The connections must be made as follows
Din to Dout pin A to pin B
Dout to Din pin B to pin A
0v to 0v pin C to pin C
CTS to RTS pin D to pin E
RTS to CTS pin E to pin D
Once the two machines are connected, switch on the power for both and configure the known working microcomputer to accept RS423 as input by typing
*FX2,2
This command will cause the microcomputer to accept input from both the keyboard and RS423, so keyboard commands will still work.
Now type the following BASIC program into the suspect microcomputer
10 *FX3,5
20 REPEAT
30 PRINT "U";
40 UNTIL 0
This program configures the suspect microcomputer to give output to the RS423 and to the screen. It then prints the character "U", whose
ASCII code is &55. &55 is a good number for testing the RS423 because it consists of alternating bits 01010101.
RUN the program.
If the known working microcomputer starts printing UUUUUUUUUUUUUUUUUUUU etc across the screen then the RS423 is working as a transmitter. If it works then go on to test it as a receiver.
If no output appears then test the suspect RS423 circuit as follows.
Check the Dout line either side of the driver, pins 2 and 15 of IC95. Pin 2 should be oscillating at normal TTL logic levels 0V/+5V. Pin 15 should be oscillating in phase with pin 2 but at RS423 logic levels -5V/+5V. If pin 2 is active but pin 15 is not then replace the driver IC95.
Check that the SERPROC IC85 is sending the transmit clock TXCK and receiving transmit data TXD from the 6850 IC82. These signals are on pins 26 and 22 respectively of IC85. If these signals are inactive then it is like1y that the SERPROC is faulty or cannot be addressed. Use the test program given in the cassette section above to check that the address decoding for the SERPROC and 6850 is working.
Now press CTRL BREAK on each microcomputer and swap the configurations, so that the good computer is the transmitter and the suspect computer is the receiver.
If "U" characters are output on to the monitor by the suspect computer then its RS423 is working as a receiver.
If no output appears then test the suspect RS423 circuit as follows.
Check the Din line either side of the receiver, pins 4 and 7 of IC94. Pin 4 should be oscillating at RS423 logic levels -5V/+5V. Pin 7 should be oscillating in phase with pin 4 but at normal TTL logic levels 0V/+5V. If pin 4 is active but pin 7 is not then replace the receiver IC94.
Check that the SERPROC IC85 is sending the receive clock RXCK and receive data RXD to the 6850 IC82. These signals are on pins 26 and 22 respectively of IC85. If these signals are inactive then it is likely that the SERPROC is faulty or cannot be addressed. Use the test program given in the cassette section above to check that the address decoding for the SERPROC and 6850 is working.
The alternative way of testing RS423 without using another microcomputer is to connect RTS to CTS and Dout to Din. Then if the BASIC program above is used to transmit data its path can be followed from the data bus through the 6850, SERPROC, drivers, out through the connector and back again through the receivers, SERPROC and through RXD back to the 6850. This loop allows all the components of the RS423 circuit to be checked as above.
9.9 Keyboard
Keyboard problems either show up as a single key which won't work reliably, or a whole group of keys which refuses to operate.
The single key fault is caused by that particular switch having worn out, or the track becoming broken by excess force. Replace the key or solder the track.
For multiple key problems, the first thing to check is that the connectors are inserted correctly. It is easy to displace either connector of the keyboard ribbon cable one pin to the left or right. If the connections are good then check that one of the wires in the cable itself hasn't been broken where it is held by the connector. Replace the ribbon cable with a good one. Try replacing the whole keyboard assembly with a good one. If it still doesn't work then there is probably a fault in the computer itself. Use a PORT tester.
9.10 Disc interface
8271: check all links are in correct position for 8271 operation:
S1 North (
PCB LINK)
S2 North (
PCB LINK)
S3 South (
PCB LINK)
S4 South (
PCB LINK)
S6 South (
PCB LINK)
S7 West
S8 open circuit
Check that all ICs and passives are fitted and inserted correctly, see 8271 disc upgrade, section 6.2.
Use a PORT tester to check that the disc interface is the problem.
Check that a disc filing system ROM has been fitted e.g. DNFS. If the filing system is stored in an
EPROM (as opposed to a mask ROM) then make sure that pin 27 is connected to 5V.
Connect a known working dual 80 track disc drive.
Turn the microcomputer on. Check that the start-up message indicates a filing system ROM is present.
Acorn OS 64K
Acorn DFS
BASIC
>
Results: If the message does not report the "Acorn DFS" then check the IC socket by fitting a known good language ROM. Check the DFS (or DNFS) ROM in another machine. If both are OK then check the 8271 (IC15) and the chip select logic, check for correct data, address, RD and WR signals at IC15. Check for 2MHz on pin 3 and for a reset pulse on pin 4 (when break key used) of IC15.
Press SHIFT and BREAK, then release BREAK while holding SHIFT down. Drive 0 should start (the LED on the front of the drive comes on).
Results: if the drive fails to come on then test that pin 38 IC15 is high (pin 10 IC8 low).
Results: if pin 10 IC8 goes low then check the connection from IC8 to PL8. If pin 10 IC8 is high then first check that a DNFS ROM is fitted and is plugged in correctly. Try fitting a good 8271. Then run the following program and check that the 8271 is being selected using an oscillosope on IC15 pin 24.
10 fdc% = &FE80
20 DIM P% 100
30 [
40 . start%
50 LDA fdc%
60 JMP start%
70 ]
80 CALL start%
If drive does come on with SHIFT BREAK then insert a known good 80 track disc into drive 0. Use a disc which has a number of files on it, and make sure that a write protect tab is fitted. Shut the drive door.
Try *CAT to get a catalogue of the disc. If no catalogue appears then check that S7 is fitted West. Check that notCS pulses low (pin 24 IC15). If not then check decoder IC28.
Check that after a BREAK a pulse occurs on pin 7 IC15. If not then check decoder IC28.
Check that RDY pins 5 and 32 of IC15 are low. If RDY is high then check S2, and for 2MHz at pin 3 IC15. If 2MHz is missing then link S6 is probably open circuit, if 4MHz then S6 set incorrectly. Check that index pulses are reaching IC3 pins 3 and 11. If not then either S4 is wrong or the disc drive is faulty. If index pulses are reaching IC3 but RDY is not going low then the disc may not be reaching speed. Measure the index pulse frequency. It should be 5Hz +/-3%.
Use an oscilloscope to monitor data on the signal end of R7. The data should be negative-going 1µs pulses with intervals of 4 or 8µs between them. If not then check connections to PL8.
1770: check all links are in correct position for l770 operation:
S3 South (
PCB LINK)
S4 South (
PCB LINK)
S5 broken
S7 East
S8 made
Check that all ICs and passives are fitted and inserted correctly, see 1770 disc upgrade, section 6.1.
Use a PORT tester to check that the disc interface is the problem.
Check that a disc filing system ROM has been fitted, e.g. 1770 DFS or ADFS. If the filing system is stored in an
EPROM , check that pin 27 of the
EPROM is connected to 5V. For tests that follow we shall assume the use of the 1770 DFS, so fit this ROM if it is not already in place.
Connect a known working dual 80 track disc drive.
Turn the microcomputer on. Check that the start-up message indicates a filing system ROM is present.
Acorn OS 64K
1770 DFS
BASIC
>
Results: if the message fails to say 1770 DFS then check the ROM socket and the ROM. If the ROM works OK then check that the data, address and control signals are reaching the 1770, IC16. Check for pulses on pin 1 of IC15 after a break. If there are none, check the address decoding logic.
Press SHIFT and BREAK, then release BREAK while holding SHIFT down. Drive 0 should start (the LED on the front of the drive comes on).
Results: if drive doesn't come on then check using an oscilloscope or logic probe that M0 (pin 20 IC16) is high, notMOTOR (pin 10 IC8) is low. Check that S0 (pin 7 IC17) is high, notS0 (pin 8 IC7) is low. If the above signals are correct then check the connection from IC7 and IC8 to connector PL8. If the above signals are wrong then try a good 1770 and check IC17. Check that IC17 is reset after a BREAK (all outputs low). Check IC17 function by poking values between 0 and 64 into location &FE80. Check that the correct bit pattern appears on the outputs.
If drive does come on with SHIFT BREAK then insert a known good 80 track disc into drive 0. Use a disc which has a number of files on it, and make sure that a write protect tab is fitted. Shut the drive door.
Try *CAT to get a catalogue of the disc. If no catalogue appears then check that S7 is fitted East. If an incorrect catalogue is obtained then check that S8 is fitted. This fault is unlikely if the disc system has worked before, but likely after an upgrade.
Check that after a BREAK a chip select (notCS) pulse occurs on pin 1 IC16. If not then check decoder IC28.
Use an oscilloscope to monitor read data (notRD) on pin 19 IC16, or the signal end of R7. The data should be negative-going pulses of period 4µs or 8µs. If not then check connections to PL8. Replace 1770.
9.11 Printer port
Use a PORT tester to check that the printer port is faulty.
Test the VIA (IC10) by writing values to it and testing the outputs. First configure all the data lines as outputs by writing &FF to the data direction register A (DDRA)
?&FE63=&FF
Then write &00 to the output register
?&FE61=&00
All the data lines to the printer connector PL9 should now be low, pins 3 5 7 9 11 13 15 and 17. If they are not all zero then check them at the VIA itself, pins 2 3 4 5 6 7 8 and 9 of IC10. If these are all low then the buffer IC5 is faulty. Otherwise check for open circuit tracks on data lines on both the printer side and the CPU side of the VIA.
Now write &FF to the output register
?&FE61=&FF
All the data lines to the printer connector PL9 should now be high, pins 3 5 7 9 11 13 15 and 17. If they are not all 1 then check them at the VIA itself, pins 2 3 4 5 6 7 8 and 9 of IC10. If these are all high then the buffer IC5 is faulty. Otherwise check for short circuit tracks on data lines on both the printer side and the CPU side of the VIA.
A better test is to use the binary configuration 10101010 on the outputs, and then change it to 01010101. These correspond to the values &AA and &55. This way short circuits are more likely to give the wrong value in the tests.
Connect a known good printer to the microcomputer. Check that the printer strobe output from the VIA pin 39 IC10 gives a 4µs negative going pulse when the computer is instructed to print. If it does then check this pulse at pin 14 IC13. If the printer interface is working correctly then there should be regular strobe pulses until the printer buffer is full. If there is only a single pulse then check the printer ACK input pin 40 IC10. These two lines together (strobe and ACK) perform the data control handshake and, on being instructed to print, the two signals ought to alternate until the printer buffer is full. If the computer is sending a strobe pulse but no ACK is coming back from the printer then the connections to the edge connector PL9 are faulty. If the strobe pulse is not being sent then the fault is either a broken track or the VIA chip itself.
9.12 User port
Use a PORT tester to check that the user port is faulty.
Test the VIA (IC10) by writing values to it and testing the outputs. First configure all the data lines as outputs by writing &FF to the data direction register B (DDRB)
? &FE62=&FF
Then write &00 to the output register
?&FE60=&00
All the data lines to the user connector PL10 should now be low, pins 6, 8, 10, 12, 14, 16, 18 and 20. If they are not all zero then check for open circuit tracks on data lines on both the printer side and the CPU side of the VIA.
Now write &FF to the output register
?&FE60=&FF
All the data lines to the user connector PL10 should now be high. If they are not all 1 then check for short circuit tracks on data lines on both the printer side and the CPU side of the VIA.
A better test is to use the binary configuration 10101010 on the outputs, and then change it to 01010101. These correspond to the values &AA and &55. This way short circuits are more likely to give the wrong value in the tests.
9.13 1MHz extension bus
Use a PORT tester. If the 1MHz extension bus is faulty then the PORT tester may show up all kinds of errors, because it is driven through the 1MHz bus.
Use the following program to exercise the FRED and JIM address decoding.
10 fred% = &FC00
20 jim% = &FD00
30 DIM P% 100
40 [
50 . start%
60 LDA# &00
70 .loop%
80 STA fred%
90 STA jim%
100 JMP loop%
110 ]
120 CALL start%
RUN the program and test pins 4 and 5 IC28 for the FRED and JIM signals, which should be pulsing low for 1µs or 1.5µs (depending on the CPU's synchronisation to 1M). If not then replace IC28. If the signals are good then test them at pins 16 and 14 IC6.
Check that the ROM output enable pin 6 IC40 is high (ROM disabled) when either FRED or JIM is low.
Check that SYNC 1M pin 8 IC41 is high when either FRED or JIM is low.
Check that the data bus buffer enable pin 19 IC12 is low (enabled) when either FRED or JIM is low.
All the above three signals come indirectly from pin 11 IC34.
Check that the data bus D0-D7 goes low both sides of the buffer at some point after the buffer is enabled (pin 19 IC12 goes low).
9.14 TUBE interface
Use a PORT tester to check that the TUBE interface is faulty.
Run the following test program
10 tube% = &FFE0
20 DIM P% 100
30 [
40 . start%
50 LDA# &00
60 .loop%
70 STA tube%
80 JMP loop%
90 ]
100 CALL start%
Test the enable pin 19 IC14 with an oscilloscope and check that the signal is wobbling. If not then check the address decoding performed by IC21 and IC22.
Check that all data lines both sides of the buffer pins 11-18 and pins 9-2 of IC14 (D0-D7) go low at some point after the enable pin 19 IC14 goes low.
Change line 50 of the program to
50 LDA# &FF
and check that all the buffered data lines go high at some point after the enable pin 19 IC14 goes low.
If these tests do not give correct results then check the data bus buffer IC14 and the
PCB tracks and connections to PL12.
50 LDA# &AA
and
50 LDA# &55
can also be tried. These correspond to output bit patterns 10101010 and 01010101.
A0-A4, R/notW, and 2E can be looked for on pins 12 9 7 5 3 16 and 18 of IC13. These signals should be the same as the system signals, but delayed by 10-15ns.
9.15 Analogue to digital conversion
Use a PORT tester to verify that the ADC circuit is faulty.
Check VREF by measuring the voltage between pin 8 IC84 and ground. This voltage should be approximately 1.8V. Look for shorted or broken tracks if it is not.
Connect two known working 2-way joysticks to the D-type connector SK6 used for the ADC. Type in and RUN the following program.
10 VDU 23,1,0;0;0;0;
20 CLS
30 REPEAT
40 PRINT TAB(0,0); ADVAL(1); SPC(4)
50 PRINT TAB(0,2); ADVAL(2); SPC(4)
60 PRINT TAB(0,4); ADVAL(3); SPC(4)
70 PRINT TAB(0,6); ADVAL(4); SPC(4)
80 UNTIL 0
Move the joysticks and see if you can get numbers in the range 0 to 65520 on each of the 4 channels. (In practice it may well not be possible to get near either one or both of the end values, but a good range of numbers on each channel is sufficient to show that the converter is working.)
If this experiment does not work then check that the ADC IC can be accessed by running the following program.
10 adc% = &FEC0
20 DIM P% 100
30 [
40 . start%
50 LDA adc%
60 JMP start%
70 ]
80 CALL start%
Check that pin 23 IC84 is active. If not then check the address decoding and connections from pin 9 IC21.
Press CTRL BREAK and look at the signal on pin 28 IC84. This line signals the end of a conversion and should be pulsing low approximately once every 10ms. If it is, but there is still a problem with A to D conversion, then check that the EOC signal is reaching pin 18 IC20.
9.16 ECONET
ECONET can only be serviced properly by ECONET service centers, who will have the necessary test equipment to check the system thoroughly. However, there are a few simple things which can be checked without the test equipment.
Check that all the ECONET components are installed and have been fitted correctly, see 6.3.
Check that
